1. 300L SUS304 Stainless Steel Tank -Ultrasonic cleaner’s tank is made of 2mm thickness SUS304 stainless steel; good corrosion resistance and heating resistance |
2. High power heating element - fast heating, saving heating time- we can adjust the heating water temperature up to 167ºF during use cleaner. |
3. 28kHz frequency is stronger cleaning effect and suitbale for cleaning auto parts. |
4. Spigot for Easy Draining. |
5. Digital temperature control. |
6. Casters for portability. |
7. Digital timer-controlled ultrasound and adjust the desired temperature. |
8 Including Attachments: Sound proof lid,Power lead , big Mesh basket, small Mesh basket |
ULTRASONIC CLEANER- cleaning machinery and manufacturing equipment, laboratory equipment, medical equipment, precision instruments, aerospace, ships, automobile maintenance and other industries play a very important role.
It cleans contaminants quickly and effectively and is compatible with aluminum and other materials commonly used in parts such as aluminum, stainless steel, Inconel, titanium, etc. Ultimately, our powerful and customizable ultrasonic systems provide eco-friendly, fast, precise and thorough cleaning that saves you time and money in the long run.
Application
- Automotive
- Aerospace industry
- Ship maintenance
- Repair and mainteance industry
- Precision metal industry
- Electronic & semiconductor industry
Notes:
1) During use ultrasonic cleaner we suggest that the general working temperature of the ultrasonic cleaner is about 55 degrees (131ºF), and the long-term working temperature should not exceed 75 degrees (167ºF), long-term working at high temperatures affect the life of the transducer.
2) DO NOT turn on ultrasonic and heating functions if there is no water in the cleaning tank.
3) The parts need to be put into the cleaning tank for cleaning through the basket, and it cannot be directly put into the working tank for cleaning;
4) When the parts are placed and taken out of the cleaning tank, turn off the ultrasonic work first;
5) The choice of cleaning detergent should satisfy 7≤Ph≤13;
6) The moving device of the equipment is only used for the moving position of the tank body when it is vacant, and cannot be used to fill the liquid or clean the parts frequently.
Model | DS-300L-28T |
Tank Size | L39.3" x W21.6" x H22" |
Tank Volume | 81 Gal |
Ultrasonic Power | 1.8 kw |
Ultrasonic Frequency | 28 Khz |
Heating Power | 10 kw |
Machine Size | 57" x 40" x 35" |
Big Basket Size | 37" x 20" x 17" |
Small Basket Size | 16" x 12" x 6" |
Max Load Capacity | 260 lb |
Voltage | 3 Phase 220V |
Frequency | 60Hz |
Max. Current | 33A |
Packing Size | 61" x 40" x 42" |
N.W. | 595 lb |
G.W. | 700 lb |
